Description
Very high efficiency double pulley with swivel
Details
Detailed description
Description
Designed for maximum simplicity when setting up haul systems or tyroleans for work at height or rescue:
- triple-action opening of the moving side plate is quick and easy, even with gloves
- the rope can be installed with the device connected to the anchor.
- red mark provides a visual warning when the moving side plate is unlocked
- special side plate design protects the rope path
Optimal efficiency:
- large diameter sheaves mounted on sealed ball bearings for excellent efficiency
Parallel:
-mounted sheaves and auxiliary attachment point for setting up various types of complex haul systems
Easy handling:
- swivel allows pulley to be oriented under load
- swivel accepts up to three carabiners
- swivel and auxiliary attachment point allows the use of ropes and slings to facilitate maneuvers.
Specifications
Weight: 480 g
Certification(s): CE EN 12278, NFPA 1983 Pulley General Use, UIAA
Material(s): aluminum, stainless steel, nylon
Min. rope diameter: 7 mm
Max. rope diameter: 13 mm
Sheave type: sealed ball bearings
Sheave diameter: 38 mm
Maximum working load: 8 kN (3 kN per strand, more information in the Instructions for Use)
Breaking strength: 36 kN
Efficiency: 95 %
Referenencs
Color: Yellow
Guarantee: 3 years
Inner Pack Count: 1
- nfpa-certified:
- General
- Item Status:
- Active
- Manufacturer Part Number:
- P001CA00
- Country of Manufacture:
- FR
